歐美晶振
- 產品型號：26887840
- 晶振頻率：32.768KHz
- 晶振尺寸：8.0*3.8*2.5mm
- 產品應用： 歐美進口晶振,Geyer晶振,KX-327ST千赫晶體,12.87114晶振,無源晶振,石英晶體諧振器,8038mm晶振,四腳貼片晶振,頻率32.768KHz,負載12.5pF,頻率容差20ppm,工作溫度-40~85°C,高穩定性晶振,無鉛環保晶振,低老化晶振,物聯網...
-
12.87114|32.768KHz|12.5pF|Geyer千赫晶體
12.87114|32.768KHz|12.5pF|Geyer千赫晶體,歐美進口晶振,Geyer晶振,KX-327ST千赫晶體,12.87114晶振,無源晶振,石英晶體諧振器,8038mm晶振,四腳貼片晶振,頻率32.768KHz,負載12.5pF,頻率容差20ppm,工作溫度-40~85°C,高穩定性晶振,無鉛環保晶振,低老化晶振,物聯網晶振,無線路由器晶振,醫療電子設備晶振,調制解調器晶振.
12.87114|32.768KHz|12.5pF|Geyer千赫晶體規格表
| part no. | 12.87114 |
| model | KX-327ST |
| frequency | 32.768 kHz |
| operating temperature | -40°~+85℃ |
| frequency tolerance(df/F) at +25°C ±3°C | 土20ppm |
| temperature tolerance (parabolic coefficient) |
-0.034 ±0.006 ppm / °C2 typ., -0.042 ppm / °C2 max
|
| turnover temperature | +25°C±5℃ |
| storage temperature range | -55°C~+125℃ |
| load capacitance CL | 12.5 pF |
| motional capacitance( Co) | 0.9 pF |
| series resistance R1 (ESR) max. | 50 KOhm |
| aging at +25°℃ (first year) max. | ±3 ppm |
| drive level | 1 μW max. |
| contents of reel | 3000 pcs. |
.jpg)
12.87114|32.768KHz|12.5pF|Geyer千赫晶體尺寸圖
